Press Brake Bending Angle Measurement

More productive sheet metal machines, new customized solutions, and easy-to-use option suites are designed to meet the customer’s real needs.

Iris Plus Angle Measurement System

Automatic angle measurement and automatic correction of the bending angle:
IRIS Plus real time angle correction An important device for the most demanding applications and the IRIS Plus comprises a laser transmitter and receiver set mounted to the upper beam of the press brake. It includes a high speed digital camera and image data processing system contained within the receiver unit.

Iris-Plus-Angle-Measurement-System
Laser-Check-Angle-Measurement-System

Laser Check Angle Measurement System

The iMeasure Laser angle measurement system with Data-M Engineering for an accurate bend angle after only one bending operation.
The iMeasure are fully-automatic laser-assisted bend angle measurement systems for CNC press brakes. Irrespective of the properties or thickness of the material, the LaserCheck enables an exact determination of the bending angle with an accuracy of better than 0.1°. This represents precision which has never been available before.

Advantage:

Embedded Solutions OEM Premium Range FOR PRESS BRAKES
